Ups 12v 50ah Rechargeable Batteries Sealed Lead Acid Vrla 6-Gfm-50
| Place of Origin | China |
|---|---|
| Brand Name | LIRUISI |
| Model Number | 6-GFM12-50 |
| Minimum Order Quantity | 1 set |
| Price | negotiation |
| Packaging Details | GFM 12V Gel Sealed Battery Product Specifications: Standard Configuration |
| Delivery Time | 8 working days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 9999 units |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Usage | UPS | Voltage | 12V |
|---|---|---|---|
| Application | UPS, Solar System, Telecom, Etc. | Product Name | Sealed Rechargeable Battery |
| Terminal | F12(M8)/F5(M8) | Electrolyte | Sulfuric Acid Gel |
| Capacity | 50Ah | Charge Time | 2-24 Hours |
| Discharge Time | 2-24 Hours | Life Cycle | 300-1000 Cycles |
| Operating Temperature | -20°C To 60°C | Safety Protection | Overcharge, Overdischarge, Short Circuit |
| Size | Small, Medium, Large | Storage Temperature | -20°C To 60°C |
| Type | Lead Acid Batteries | Warranty | 1-5 Years |
| Weight | 2Kg-3000Kg | ||
| High Light | 12v rechargeable batteries sealed lead acid,ups rechargeable batteries sealed lead acid,50ah solar charging lead acid batteries |
||
Product Description
Product introduction:
UPS battery GFM 12V gel sealed battery is usually used as a backup power source in UPS systems, which can provide continuous and stable power supply when the mains power is interrupted to ensure the normal operation of the equipment.
Product parameters:
| Model | standard voltage | 20HR capacity | Overall dimensions (mm) | Total weight Approx. (kg) | |||
| Length (L) | Width (W) | High (H) | Total height (TH) | ||||
| 6-GFM-50 | 12 | 50 | 260 | 133 | 205 | 205 | 17.0 |
Installation, use and maintenance
Connection of the battery:
The positive and negative poles shall not be reversed or short-circuited
The batteries of the battery pack should be spaced more than 10mm apart to facilitate heat dissipation
Battery charging:
The maximum current shall not be greater than 25% of the nominal capacityNote: The battery should not be used in a closed or high temperature environment and should be kept away from fire
Storage and installation:
Insulating tools should be used during installation to prevent electric shock
Notes:
Check regularly (once a year) whether the connecting wire is loose, and if there is looseness, it should be tightened
Regularly (once every three months) wipe the battery with a soft fabric to keep the battery clean
Do not use organic solvents to clean the battery
Pay attention to the battery interval to prevent salt bridges
