R Series UPS Uninterruptible Power Supply High Frequency 4800W 6KRVA UPS Battery
| Place of Origin | China |
|---|---|
| Brand Name | Liruisi |
| Model Number | 6KRVA |
| Minimum Order Quantity | 1Section |
| Price | bargaining |
| Packaging Details | Rackmount size: 3K(R): 438mm(W) x 88mm(2U)(H) x 480mm(D) Built-in battery included |
| Delivery Time | 8 working days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 999 units |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type | On-line | Application | Security / Monitoring / Alarm |
|---|---|---|---|
| Protection | Overvoltage | Output Voltage Accuracy | ±1% |
| Specifications | 6KVA/4800W | Product Name | Online UPS Systems |
| High Light | 4800W UPS Uninterruptible Power Supply,6KVA UPS Uninterruptible Power Supply,High Frequency 6KVA UPS Battery |
||
Product Description
Introduction of R series E6RS UPS uninterruptible power supply for high frequency machine:
R series E6RS is a high-frequency UPS uninterruptible power supply developed and produced by China Electric Power Research Institute. After a number of technical improvements, it has higher efficiency and more stable performance. The product adopts dual-converter online AC mode, which can provide up to 95% transmission efficiency, and has multiple protection functions, including overload, overvoltage, undervoltage, short circuit, etc.
How it works:
Three-in single-out, double-conversion online work order in single-out operation
Core advantages:
It is suitable for separate use in the cabinet or outside the cabinet.DSP digital control, the control system is more stable and reliable, excellent performance,Dual conversion online design using input power correction (PED) technology. Input power up to 0.99.Machine efficiency up to 96%The output power factor is 0.8/0.9/1 optional, with higher actual load capacity, saving user investment.
Medical equipment: In medical equipment, various instruments need a continuous and stable power supply. If the instruments fail or data is lost due to power fluctuations, voltage surges, etc., this will have a serious impact on patient health. R series E6RKVA high-frequency machine UPS uninterruptible power supply can provide stable power protection to ensure the normal operation of medical equipment and patient safety.
Technical parameters:
| Single Input Single Output High Frequency Rack UPS System | |
| Product model | Single-phase electrical input, single-phase electrical output |
| 6KRVA | |
| Specifications | 6KVA/4800W |
| Performance parameters | |
| Input voltage range |
High voltage version HV: zero fire phase voltage: 90~300VAC Low voltage version LV: zero fire phase voltage: 55~145VAC |
| Input power factor | ≥0.99 |
| Input frequency range | 40Hz-70Hz |
| Number of output lines | Single-phase two-wire (L, N) + protected ground |
| Rated voltage | 208/220/230/240VAC |
| Output voltage accuracy | ±1% |
| Output frequency | 50/60±4Hz (phase-locked follows mains) / 50/60Hz±0.1% (fixed frequency mode) |
| Output waveform | Pure sine wave |
| Output distortion(THDV%) | < 2% (linear load), < 7% (nonlinear load) |
| Overload capacity | 10 minutes @ 105% ~ 125% rated load, 1 minute @ 125% ~ 150% rated load |
| Number of batteries | 16*12/7AH |
| Battery DC voltage | 192VDC |
| Rack Battery Case Size | 2U:438*132*550 |
| Rack UPS Host Size | 2U rack type: 438 * 88 * 360mm |
